| Mechanical range of the gimbal | Tilt: -45° to 45° |
| Sensor system type | Multidirectional |
| Adjustable rotation range of the gimbal | Tilt: -90° to +30° |
| Maximum angular velocity | 1 AC power socket (support for 2 plug types) Tilt: 300°/s, Tilt: 120°/s |
| Maximum take-off height | 7000 m |
| Frequency band | 2.4 GHz/5.2 GHz/5.8 GHz/900 MHz |
| NavIC | Jā |
| Wi-Fi | Jā |
| Wi-Fi Direct | Jā |
| GPS (satellite) | Jā |
| GLONASS | Jā |
| Maximum range | 20000 m |
| Quasi-Zenith Satellite System (QZSS) | Jā |
| Hovering time (max) | 38 min |
| Maximum ascent speed | 8 m/s |
| BeiDou | Jā |
| Galileo | Jā |
| Number of axis | 3 |
| Maximum descent speed | 6 m/s |
| Maximum speed | 23 m/s |
| Maximum flight time | 42 min |
| Maximum tilt angle | 35° |
| Millimetre-wave radar sensor system | Jā |
| Optical sensor system | Jā |
| Return Home function | Y |
| Maximum wind resistance (take-off and landing) | 12 m/s |
| Maximum number of targets detected | 32 |
| Zoom camera (telephoto) | Jā |
| Thermal imaging camera | Y |
| Laser distance measurer | 1200 m |
| RTK module | Optional |
| Easy to use | Jā |
| Product colour | Metallic |
| Type | Drone |
| International Protection (IP) code | IP43 |
| Number of cameras | 3 |
| Number of rotors | 4 rotors |
| Number of propeller blades | 2 |
| Operating temperature (T-T) | -10 - 40 °C |
| Flight modes | Follow Me mode |
| Moving control functions | Upward |
| Auto takeoff function | Jā |
| Obstacle sensing system | Y |
| Auto return function | Y |
| Auto landing function | Jā |
| Weight | 1.6 kg |
| Product dimensions when open (WxDxH) | 257 x 136 x 133 mm |
| Product dimensions when closed (WxDxH) | 340 x 407 x 148 mm |
| Transmitter dimensions | 303 x 190 x 87 mm |
| Transmitter weight | 1150 g |
| Controller charger | Jā |
| Set contents | Autel V3 controller |
| Spare propeller(s) included | 1 pairs |
| Power supply cable | Jā |
| Number of batteries | 1 |
| Manual | Jā |
| Cables included | Data cable |
| Battery charger included | Jā |
| Carrying case | Jā |
| Screwdriver included | Jā |
| Gimbal protector | Y |
| Memory card included | 64 GB |
| ISO sensitivity (photos) | 100 - 6400 |
| Fixed focal length of second camera | 9.1 mm |
| Thermal imaging camera | Y |
| ISO sensitivity (video) | 100 - 64000 |
| Angle of field of view of the thermal imaging camera (FOV) | 61° |
| Aperture | F1.9 |
| Maximum frame rate | 60 fps |
| Megapixel (approx.) | 50 MP |
| Camera shutter speed | 8 -1/8000 s |
| Video streaming | Jā |
| Maximum video resolution | 3840 x 2160 pixels |
| Video formats supported | MP4 |
| Image formats supported | JPG |
| Fixed focal length | 23 mm |
| Supported video modes | 4K |
| Field of view (FOV) angle | 85° |
| High Dynamic Range (HDR) supported | Jā |
| Live view | Jā |
| Zoom range of camera with night vision mode | 8x |
| Maximum still image resolution of camera with night vision (Night Vision) | 1920 x 1200 px |
| Focal length of camera with Night Vision mode | 35 mm (41.4 mm equivalent) |
| Maximum video resolution of camera with night vision (Night Vision) | 1920 x 1200 px |
| Sensor | CMOS 1/1.28" |
| Camera with Night Vision | Y |
| Baud rate | 120 Mbps |
| Sensor resolution (thermal module) | 640 x 512 px |
| Temperature range (thermal imaging camera) | High gain mode: -20° to +150° |
| Number of megapixels of the camera with Night Vision mode | 2,3 MP |
| Angle of Field of View (FOV) of the camera with Night Vision mode | 52° |
| Thermal camera aperture | F/1.0 |
| Camera resolution | 8192 x 6144 pixels |
| Camera pixel size | 12 µm |
| Time-lapse recording | Jā |
| Charging time (transmitter) | 120 min |
| Battery life (transmitter) | 4.5 h |
| Battery voltage | 14.88 V |
| Battery capacity | 8070 mAh |
| Battery technology | Lithium polymer (LiPo 4S) |
| Transmitter battery capacity | 5800 mAh |
| Charging temperature | 5 - 45 °C |
| iOS compatibility | Jā |
| Applications supported | Autel Sky |
| Operated via Android devices | Jā |
| Brand specific technologies | Mesh network technology - A-Mesh 1.0 |
| Image transmission - transmitter power (EIRP) | SRRC: ≤20dBm - 2.4G, ≤33dBm - 5.8G/5.7G |
| Maximum brightness | 2000 nits |
| Transmission range | 8 km (CE) |
| Number of USB Type A ports | 1 |
| Transmission system | Autel SkyLink |
| Bluetooth transmitter power | 11 dBm |
| Maximum frame rate | 60 fps |
| Display resolution | 2048 x 1536 pixels |
| Processor family | Qualcomm |
| HD type | Ultra HD |
| Bluetooth version | 5.0 |
| Bluetooth | Jā |
| Display diagonal | 20.1 cm (7.9") |
| Built-in display | Jā |
| Touchscreen | Jā |
| HDMI ports quantity | 1 |
| Interface type | HDMI/USB |
| Compatible memory cards | Not supported |
| Battery technology | Lithium-Ion (Li-Ion) |
| International Protection (IP) code | IP43 |
| Antennas quantity | 2 |
| Processor cores | 8 |
| Removable battery | Nē |
| USB Type-C ports quantity | 1 |
| Built-in WiFi | Jā |
| Built-in memory capacity | 128 GB |
| Operating frequency (RF) | 902-928 MHz, (FCC), 2.400-2.4835 GHz, 5.725-5.850 GHz |
