| System | | Main Processor | Industrial-grade embedded processor | | OS | Embedded Linux | | Operation Interface | Web/operating in local GUI | | Perimeter Protection by Camera | | Performance | 8 channels | | AI Search | Search for pictures by channel, time and event type | | Face Detection by Camera | | Performance | 4 channels | | Face Attributes | 6 attributes: Gender, age, glasses, expression, mouth mask, and beard | | AI Search | Search for pictures by channel, time and face attributes | | SMD Plus by Camera | | Performance | 8 channels | | AI Search | Search by target classification (human, vehicle) | | Video | | Access Channel | 8 | | Network Bandwidth | Access: 80 Mbps; Storage: 80 Mbps; Forward: 60 Mbps | | Resolution | 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1 | | Decoding Capability | 8 × 1080p@30 fps | | Video Output | 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI | | Multi-screen Display | 1, 4, 8, 9 views | | Third-party Camera Access | ONVIF; RTSP | | Compression | | Video | Smart H.265/H.265/Smart H.264/H.264/MJPEG | | Audio | PCM/G711A/G711U/G726/AAC | | Network | | Network Protocol | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register | | Mobile Phone Access | Android; iOS | | Interoperability | ONVIF(profile T/S/G); CGI; SDK | | Browser | Chrome; IE9 or later; firefox | | Record Playback | | Multi-channel Playback | Up to 8 channels for playback | | Record Mode | Manual record; alarm recording; SMD recording; smart recording | | Storage | Local HDD; network | | Backup | USB storage device | | Playback Function | 1. Play/pause/stop/slow/quick/backward/by frame
2. Full screen, backup (video clip/file), partial zoom in, and audio on/off | | Storage | | | Disk Group | Yes | | Alarm | | General Alarm | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm | | Anomaly Alarm | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception | | Intelligent Alarm | Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms | | Alarm Linkage | Recording, snapshot, audio, buzzer, log, preset, and email | | External Port | | Audio Input | 1 × RCA input | | Audio Output | 1 × RCA output | | HDD | 1 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature | | USB | 2 (2 × back USB2.0) | | HDMI | 1 (supports up to 4K resolution output) | | VGA | 1 | | Network | 1 × RJ-45, 10/100 Mbps self-adaptive Ethernet port | | POE | 8 | | General Parameter | | Power Supply | DC48V/53V, 2A/1.8A | | Power Consumption | < 10 W (HDD not included, idling)
Total output power of PoE is 72W, the maximum output power of a single port is 25.5W | | Net Weight | 0.70 kg (1.54 lb) | | Gross Weight | 1.80 kg (3.97 lb | | Product Dimensions | 270 mm × 206.5 mm × 47.5 mm (10.63" × 8.13" × 1.87") (W × L × H) | | Package Dimensions | 96 mm × 427 mm × 262 mm (3.78" × 16.81" × 10.31") (W × L × H) | | Operating Conditions | –10 °C to +50 °C (+10 °F to +122 °F) | | Storage Conditions | 0 °C to +40 °C (32 °F to 104 °F) | | Operating Humidity | 10?~93? | | Storage Humidity | 30%~85% | | Operating Altitude | 3000 m (9842.52 ft) | | Installation | Desktop mounted | | Certifications | CE: EN62368-1; EN55032,EN55024, EN55035, EN61000-3-2, EN61000-3-3 EN50130-4
FCC: Part 15 Subpart B | |
