| Category Code | FNC |
| CnCode | 85258900 |
| Unit Box Height | 0.1 |
| Unit Box Length | 0.22 |
| Unit Box Width | 0.13 |
| Form factor | Bullet |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Mounting type | Wall |
| Product colour | White |
| Protection features | Waterproof |
| Weatherproof | Jā |
| Connectivity technology | Wired |
| Day/night mode | Jā |
| Dynamic range | 120 dB |
| Infrared (IR) cut-off filter | Jā |
| Maximum operating distance | 64 m |
| Placement supported | Outdoor |
| Remote viewing | Jā |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Jā |
| Camera shutter speed | 1/3 to 1/10000 s |
| Lens viewing angle, diagonal | 118 ° |
| Lens viewing angle, horizontal | 100 ° |
| Lens viewing angle, vertical | 54 ° |
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 90 ° |
| Optical sensor size | 1/2.7 " |
| Progressive scan | Jā |
| Sensor type | CMOS |
| Detect distance | 64 m |
| Fixed focal length | 2.8 mm |
| Identify distance | 6 m |
| Maximum aperture number | 1.6 |
| Observe distance | 27 m |
| Recognize distance | 13 m |
| LED type | IR/White |
| Night vision | Jā |
| Back Light Compensation (BLC) | Jā |
| Bit rate | Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Digital Wide Dynamic Range (DWDR) | Jā |
| Highlight Compensation (HLC) | Jā |
| Image quality adjustment | Brightness/Contrast/Mirror/Saturation/Sharpness |
| Maximum resolution | 2688 x 1520 pixels |
| Supported graphics resolutions | 1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/2688 x 1520 |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video recording | Jā |
| Audio formats supported | G.711 A-law |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio system | 2-way |
| Bit rate range | 0 - 64 Kbit/s |
| Built-in microphone | Jā |
| Built-in speaker(s) | Jā |
| Number of microphones | 1 |
| Sample rate | 8 kHz |
| Bluetooth | Nē |
| Ethernet LAN | Jā |
| Live view | Jā |
| Networking standards | IEEE 802.3af/IEEE 802.3at |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| Wi-Fi | Nē |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 512 GB |
| DC-in jack | Jā |
| Ethernet LAN (RJ-45) ports | 1 |
| Alert notification type | Push notification |
| Built-in siren | Jā |
| Digest authentication | Jā |
| HTTPS encryption | Jā |
| Human and vehicle targets classification | Jā |
| IP address filtering | Jā |
| Mirror | Jā |
| Motion sensor | Jā |
| Password protection | Jā |
| Video motion detection | Jā |
| Cloud-managed | Jā |
| Reset button | Jā |
| Web browser | Jā |
| Web-based management | Jā |
| DC output voltage | 12 |
| Power consumption (Power over Ethernet (PoE)) | 10.7 W |
| Power source type | DC,PoE |
| Operating relative humidity (H-H) | 0 - 95 % |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -40 - 60 °C |
| Height | 74 mm |
| Length | 184 mm |
| Weight | 525 g |
| Width | 74 mm |
| Drilling template included | Jā |
| Manual | Jā |
| Mounting kit | Jā |
| Number of cameras | 1 |
| Screws included | Jā |
| Units per Shipping Box | 1 |
| Unit Calculated Volume | 0.00286 cubm |
| Unit Calculated Weight | 0.83 kg |
