| Product colour | White |
| Housing material | Metal |
| Mounting type | Ceiling/wall |
| IK code | IK10 |
| Form factor | Bullet |
| Protection features | Waterproof |
| International Protection (IP) code | IP67 |
| DC output current | 0.83 A |
| Power consumption (Power over Ethernet (PoE)) | 11 W |
| Power consumption (max) | 10 W |
| Power source type | DC, PoE |
| DC output voltage | 12 |
| IP address filtering | Jā |
| Security algorithms | TLS |
| Password protection | Jā |
| Flash log | Jā |
| Automatic Network Replenishment (ANR) | Jā |
| Human and vehicle targets classification | Jā |
| HTTPS encryption | Jā |
| Privacy protection | Jā |
| Pixel counter | Jā |
| Network access storage (NAS) | Jā |
| Audit log | Jā |
| Mirror | Jā |
| Video motion detection | Jā |
| Digest authentication | Jā |
| Active tampering alarm | Jā |
| Password reset via email | Jā |
| Heartbeat | Jā |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Reset button | Jā |
| Web browser | Jā |
| Behavior analysis | Line crossing detection |
| Web-based management | Jā |
| Length | 286.7 mm |
| Width | 93.1 mm |
| Weight | 1.11 kg |
| Height | 88.7 mm |
| Number of users | 32 user(s) |
| Number of simultaneous live view channels | 6 channels |
| Networking standards | IEEE 802.1x |
| Wi-Fi | Nē |
| Quality of Service (QoS) support | Jā |
| Ethernet interface type | Fast Ethernet |
| Client interoperability | iVMS-4200, Hik-Connect, Hik-Central |
| Ethernet LAN | Jā |
| Bluetooth | Nē |
| User access level | Administrator, Operator, User |
| Live view | Jā |
| Certification | FCC (47 CFR 15, B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Languages support | Multi |
| Connectivity technology | Wired |
| Day/night mode | Jā |
| Dynamic range | 120 dB |
| Number of languages | 33 |
| Built-in light | Jā |
| Placement supported | Outdoor |
| Infrared (IR) cut-off filter | Jā |
| Wide Dynamic Range (WDR) | Jā |
| Type | IP security camera |
| Package height | 155 mm |
| Package weight | 1.64 kg |
| Package depth | 156 mm |
| Package width | 386 mm |
| Number of cameras | 1 |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Compatible memory cards | MicroSD (TransFlash) |
| Built-in HDD | Nē |
| Card reader integrated | Jā |
| Maximum memory card size | 512 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Lens viewing angle, diagonal | 122° |
| Lens viewing angle, horizontal | 104° |
| Tilt angle range | 0 - 90° |
| Minimum illumination | 0 lx |
| Number of Privacy masking areas | 8 |
| Lens viewing angle, vertical | 57° |
| Angle of rotation | 360° |
| Pan range | 0 - 360° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Browser supported | IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ |
| Number of sensors | 1 |
| Progressive scan | Jā |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.9 mm (1 / 2.9") |
| Frame rate | 30 fps |
| Video compression formats | M-JPEG |
| Supported graphics resolutions | 640 x 360 |
| Video streaming | Jā |
| Maximum resolution | 2688 x 1520 pixels |
| Gain control type | Auto |
| Privacy masking | Jā |
| Total megapixels | 4 MP |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Highlight Compensation (HLC) | Jā |
| Back Light Compensation (BLC) | Jā |
| Bit rate | 32 Kbps - 8 Mbps |
| Noise reduction | Jā |
| Region of Interest (ROI) encoding | Jā |
| Noise reduction technology | 3D noise reduction |
| Video recording | Jā |
| Infra-red wavelength | 850 nm |
| LED type | IR/White |
| Night vision distance | 80 m |
| Night vision | Jā |
| Fixed focal length | 2.8 mm |
| Detect distance | 63 m |
| Observe distance | 25 m |
| Maximum aperture number | 1.6 |
| Recognize distance | 12 m |
| Identify distance | 6 m |
| Number of lenses | 1 |
| Compliance certificates | WEEE |
