| Form factor | Spherical |
| Product colour | Black |
| Fog proof | Jā |
| International Protection (IP) code | IP66 |
| Protection features | Waterproof |
| Mounting type | Ceiling |
| Power source type | DC, PoE |
| Power consumption (max) | 14 W |
| DC output current | 3.33 A |
| DC output voltage | 12 |
| Audit log | Jā |
| Digest authentication | Jā |
| Automatic Network Replenishment (ANR) | Jā |
| Security algorithms | EAP-LEAP |
| HTTPS encryption | Jā |
| Alarm input channels | 1 |
| Alarm output channels | 1 |
| IP address filtering | Jā |
| Intelligent Video Surveillance (IVS) system features | Crossing line |
| Video motion detection | Jā |
| Privacy protection | Jā |
| Digital watermark | Jā |
| Password protection | Jā |
| Active tampering alarm | Jā |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -30 - 65 °C |
| Web-based management | Jā |
| Width | 12.5 mm |
| Depth | 179.3 mm |
| Height | 182 mm |
| Weight | 1.12 kg |
| Number of simultaneous live view channels | 20 channels |
| User access level | Administrator, Operator, User |
| Ethernet interface type | Fast Ethernet |
| Bluetooth | Nē |
| Quality of Service (QoS) support | Jā |
| Supported network protocols | IPv4/IPv6, HTTP, HTTPS, QoS,802.1x, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour |
| Ethernet LAN | Jā |
| Wi-Fi | Nē |
| Client interoperability | iVMS-4200, HikCentral, Hik-Connect |
| Number of users | 32 user(s) |
| Live view | Jā |
| Preset freezing function | Jā |
| PTZ status display | Jā |
| PTZ modes | Preset point |
| Wide Dynamic Range (WDR) | Jā |
| Connectivity technology | Wired |
| Type | IP security camera |
| PTZ control | Jā |
| Day/night mode | Jā |
| Placement supported | Indoor & outdoor |
| Alarm input/output | Jā |
| Infrared (IR) cut-off filter | Jā |
| Dynamic range | 120 dB |
| Number of cameras | 1 |
| Bit rate range | 16 - 160 Kbit/s |
| Built-in microphone | Jā |
| Audio formats supported | G.711 μ-law |
| Built-in speaker(s) | Jā |
| Compatible memory cards | MicroSDXC |
| Card reader integrated | Jā |
| Built-in HDD | Nē |
| Maximum memory card size | 256 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Lens viewing angle, vertical | 51.1 - 17.7° |
| Lens viewing angle, horizontal | 96.7 - 31.6° |
| Number of Privacy masking areas | 24 |
| Lens viewing angle, diagonal | 115.1 - 36.3° |
| Pan range | 0 - 350° |
| Minimum illumination | 0 lx |
| Tilt angle range | 0 - 90° |
| Preset programs quantity | 300 |
| Tilt speed | 50 °/sec |
| Camera shutter speed | 1 - 1/30000 s |
| Tilt preset speed | 60 °/sec |
| Pan speed | 60 °/sec |
| Pan preset speed | 60 °/sec |
| Camera tilt control | Jā |
| Camera pan control | Jā |
| I/O ports | line in, line out |
| Browser supported | IE10-11, Chrome 57.0+, Firefox 52.0+, Safari 12+ |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Sensor type | CMOS |
| Progressive scan | Jā |
| Number of sensors | 1 |
| Bit rate | 32 Kbps - 16 Mbps |
| Supported graphics resolutions | 640 x 480 (VGA) |
| Maximum resolution | 2560 x 1440 pixels |
| Total megapixels | 4 MP |
| Back Light Compensation (BLC) | Jā |
| Highlight Compensation (HLC) | Jā |
| Frame rate | 30 fps |
| Video compression formats | H.264+ |
| Noise reduction technology | 3D noise reduction |
| Region of Interest (ROI) encoding | Jā |
| Privacy masking | Jā |
| Image quality adjustment | Sharpness |
| B/W night vision distance | 6 m |
| LED type | IR |
| Night vision distance | 50 m |
| Night vision | Jā |
| Proportional zoom | Jā |
| Zoom speed | 2 s |
| Focus | Motorized/Manual |
| Optical zoom | 4x |
| Identify distance | 18 m |
| Digital zoom | 16x |
| Maximum aperture number | 1.5 |
| Recognize distance | 36 m |
| Observe distance | 71.4 m |
| Focal length range | 2.8 - 12 mm |
| Zoom capability | Jā |
| Detect distance | 180 m |
| Auto focus | Jā |
| Number of lenses | 1 |
