| Processor generation | AMD Ryzen 7000 Series |
| Number of processors installed | 1 |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Processor base power | 65 W |
| Processor boost frequency | 5.3 GHz |
| Processor family | AMD Ryzen™ 7 |
| Processor cache | 32 MB |
| Processor cores | 8 |
| Processor frequency | 3.8 GHz |
| Processor threads | 16 |
| Processor cache type | L3 |
| Processor model | 7700 |
| On-board GPU manufacturer | AMD |
| On-board graphics card | Jā |
| AMD FreeSync | Jā |
| On-board graphics card family | AMD Radeon Graphics |
| Discrete graphics card | Jā |
| CUDA | Nē |
| Discrete graphics card memory | 16 GB |
| NVIDIA G-SYNC | Nē |
| Discrete graphics card model | AMD Radeon RX 9070 |
| NVIDIA GameWorks VR | Nē |
| On-board graphics card model | AMD Radeon Graphics |
| Graphics card DisplayPorts quantity | 3 |
| Graphics card HDMI ports quantity | 1 |
| Number of discrete graphics cards | 1 |
| Discrete GPU manufacturer | AMD |
| Discrete graphics memory type | GDDR6 |
| Maximum internal memory | 192 GB |
| ECC | Nē |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 4x DIMM |
| Memory clock speed | 6000 MHz |
| Internal memory type | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Internal memory | 32 GB |
| Internal memory manufacturer | Kingston |
| Housing material | Metal, Plastic, Tempered glass |
| Chassis type | Midi Tower |
| VESA mounting | Nē |
| Product colour | Black |
| Water cooling system | Nē |
| Refurbished | Nē |
| Number of 3.5" bays | 2 |
| Viewing window | Jā |
| Number of 2.5" bays | 3 |
| RGB backlighting | Jā |
| Power supply | 750 W |
| 80 PLUS certification | 80 PLUS Bronze |
| Power supply input voltage | 100-240 V |
| Depth | 440 mm |
| Height | 500 mm |
| Width | 230 mm |
| Weight | 10 kg |
| Wi-Fi standards | Wi-Fi 4 (802.11n) |
| Cabling technology | 10/100/1000Base-T(X) |
| Antenna type | 2x2 |
| Ethernet LAN | Jā |
| Bluetooth | Jā |
| Wi-Fi | Jā |
| Ethernet LAN data rates | 10 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Bluetooth version | 5.2 |
| Internal components | ASUS TUF GAMING B650M-PLUS WIFI / AMD Radeon RX 9070 / Kingston Fury Beast RGB / WD Blue SN5000 / ENDORFY Fera 5 Black ARGB / DeepCool PL750-D / Phanteks XT View |
| Market positioning | Gaming |
| Product type | PC |
| Audio output channels | 7.1 channels |
| Motherboard form factor | micro ATX |
| Motherboard chipset | AMD B650 |
| Virtual Reality (VR) ready | Jā |
| Powered by | VIEW |
| PCI Express x1 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 2 |
| Display included | Nē |
| Bundled software | Bitdefender Internet Security |
| Operating system installed | Nē |
| Number of storage drives supported | 6 |
| Card reader integrated | Nē |
| Number of storage drives installed | 1 |
| Storage media | SSD |
| Optical drive type | Nē |
| Total storage capacity | 1 TB |
| SSD form factor | M.2 |
| Total SSDs capacity | 1 TB |
| Intel® Optane™ Memory module installed | Nē |
| SSD interface | PCI Express |
| NVMe | Jā |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Number of front USB ports | 2 |
| Line-in | Jā |
| Headphone outputs | 1 |
| Intel® Thunderbolt 4 | Nē |
| Line-out | Jā |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| Microphone in | Jā |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| DC-in jack | Nē |
| HDMI ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| DisplayPorts quantity | 4 |
| S/PDIF out port | Nē |
| DVI port | Nē |
| Combo headphone/mic port | Jā |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of SATA III connectors | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Number of front audio ports | 1 |
| Number of rear audio ports | 5 |
| Number of rear USB ports | 8 |
| Special features | The specification and description are for illustrative purposes only. |
| TV tuner integrated | Nē |
| Built-in microphone | Nē |
