| Print Technology | Thermal Inkjet |
| Print Technology | Thermal Inkjet |
| Color / Mono | Color |
| Color / Mono | Color |
| Print Speed Color | 35 sec/page on A1, 68 A1 prints per hour |
| Print Speed Color | 35 sec/page on A1, 68 A1 prints per hour |
| Print Speed Mono | Nav |
| Print Speed Mono | Nav |
| Print Speed Features | Nav |
| Print Speed Features | Nav |
| First Page Out | 35 s |
| First Page Out | 35 s |
| Processor | Nav |
| Processor | Nav |
| Memory Standart | 512 MB |
| Memory Standart | 512 MB |
| Memory Max. | Nav |
| Memory Max. | Nav |
| HDD | Nav |
| HDD | Nav |
| Print Quality | 2400 x 1200 dpi |
| Print Quality | 2400 x 1200 dpi |
| Duty Cycle | Nav |
| Duty Cycle | Nav |
| Paper Handling Input | Nav |
| Paper Handling Input | Nav |
| Paper Handling Input Total | Nav |
| Paper Handling Input Total | Nav |
| Paper Handling Output | Nav |
| Paper Handling Output | Nav |
| Papper Trays Standard | Nav |
| Papper Trays Standard | Nav |
| Papper Trays Max. | Nav |
| Papper Trays Max. | Nav |
| Duplex Printing | Nē |
| Duplex Printing | Nē |
| ADF | Nav |
| ADF | Nav |
| ADF Capacity | Nav |
| ADF Capacity | Nav |
| Print Format | A1 |
| Print Format | A1 |
| Paper Size Max. | 279 x 610 mm rolls |
| Paper Size Max. | 279 x 610 mm rolls |
| Media Types | Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint)Technical paper (natural tracing), film (clear, matte)Photographic paper (satin, gloss, semigloss, polypropylene)Self-adhesive (adhesive, polypropylene) |
| Media Types | Bond and coated paper (bond, coated, heavyweight coated, plain, bright white, blueprint)Technical paper (natural tracing), film (clear, matte)Photographic paper (satin, gloss, semigloss, polypropylene)Self-adhesive (adhesive, polypropylene) |
| Media Sizes | 210 x 279 to 610 x 1897 mm |
| Media Sizes | 210 x 279 to 610 x 1897 mm |
| Media Weights | 60 to 280 g/m² |
| Media Weights | 60 to 280 g/m² |
| Media Weight Max. | 280 g/m² |
| Media Weight Max. | 280 g/m² |
| Languages | JPEGURF |
| Languages | JPEGURF |
| Wireless | Nav |
| Wireless | Nav |
| Card Reader | Nav |
| Card Reader | Nav |
| Connectivity | Gigabit Ethernet (1000Base-T)Hi-Speed USB 2.0Wi-Fi 802.11a/b/g/nWi-Fi Direct |
| Connectivity | Gigabit Ethernet (1000Base-T)Hi-Speed USB 2.0Wi-Fi 802.11a/b/g/nWi-Fi Direct |
| Control Panel | Nav |
| Control Panel | Nav |
| Faxing | Nē |
| Faxing | Nē |
| Fax Quality | Nav |
| Fax Quality | Nav |
| Fax Speed | Nav |
| Fax Speed | Nav |
| Colour Faxing | Nav |
| Colour Faxing | Nav |
| Digital Sending | Nav |
| Digital Sending | Nav |
| Scanning | Nē |
| Scanning | Nē |
| Scan Type | Nav |
| Scan Type | Nav |
| Scan Quality | Nav |
| Scan Quality | Nav |
| Scan Quality Hardware / Enhanced | Nav |
| Scan Quality Hardware / Enhanced | Nav |
| Scan Size Max. | Nav |
| Scan Size Max. | Nav |
| Copying | Nē |
| Copying | Nē |
| Multiple Copies | Nav |
| Multiple Copies | Nav |
| Print Features | Nav |
| Print Features | Nav |
| Software Included | HP Click App for Windows and macOSP Click Driver for Windows 11HP app for Windows, macOS, Android and iOS |
| Software Included | HP Click App for Windows and macOSP Click Driver for Windows 11HP app for Windows, macOS, Android and iOS |
| System Requirements | Nav |
| System Requirements | Nav |
| Operating System Compatibily | Nav |
| Operating System Compatibily | Nav |
| Security | Nav |
| Security | Nav |
| Width | 1013 mm |
| Width | 1013 mm |
| Depth | 440 mm |
| Depth | 440 mm |
| Height | 285 mm |
| Height | 285 mm |
| Net Weight | 21.500 kg |
| Net Weight | 21.500 kg |
| Gross Weight | 27.000 kg |
| Gross Weight | 27.000 kg |
| Warranty | 1 year |
| Warranty | 1 year |
| Package Contents | HP DesignJet T230 24-in PrinterPrintheadIntroductory ink cartridgesSpindleQuick reference guideSetup posterPower cord |
| Package Contents | HP DesignJet T230 24-in PrinterPrintheadIntroductory ink cartridgesSpindleQuick reference guideSetup posterPower cord |
| Manufacturer Datasheet | https://www.hp.com/emea_africa-en/products/large-format-printers/product-details/product-specifications/2102618089 |
| Manufacturer Datasheet | https://www.hp.com/emea_africa-en/products/large-format-printers/product-details/product-specifications/2102618089 |
