General
|
|
Function
|
Print, Copy, Scan, Fax, File
|
|
Colour or Black & White
|
Colour
|
|
Engine speed: A4 Colour (ppm)
|
31
|
|
Engine speed: A4 B/W (ppm)
|
31
|
|
Engine speed: A3 Colour (ppm)
|
16
|
|
Engine speed: A3 B/W (ppm)
|
16
|
|
Paper size: Min.
|
A6R
|
|
Paper size: Max.
|
SRA3
|
|
Paper weight: Min. (g/m²)
|
52
|
|
Paper weight: Max. (g/m²)
|
300
|
|
Paper capacity: Std. (sheets)
|
650
|
|
Paper capacity: Max. (sheets)
|
6300
|
|
Warm-up time (sec.)
|
16
|
|
Memory general: Max. (GB)
|
5
|
|
Storage: Std.
|
SSD
|
|
Storage: Opt.
|
SSD
|
|
SSD capacity: Std. (GB)
|
256
|
|
SSD capacity: Opt. (GB)
|
512
|
|
Duplex
|
Standard
|
|
Power requirements: Frequency Min. (Hz)
|
50
|
|
Power requirements: Frequency Max. (Hz)
|
60
|
|
Power consumption (kW)
|
1.84
|
|
Width (mm)
|
608
|
|
Depth (mm)
|
653
|
|
Height (mm)
|
829
|
|
Weight (kg)
|
78
|
|
Print
|
|
Network printer
|
Standard
|
|
Resolution (dpi)
|
1200 x 1200, 600 x 600, 9600 x 600
|
|
Interface: Std.
|
USB 2.0, USB 3.0, 10Base-T, 100Base-TX, 1000Base-T
|
|
Supported OS: Std.
|
Windows 10, Windows 11, Windows Server 2016, Windows Server 2019, Windows Server 2022, Windows Server 2025, Mac OS X 10.15, Mac OS X 11, Mac OS X 12, Mac OS X 13, Mac OS X 14, macOS 15
|
|
Network protocols
|
TCP/IP (IPv4, IPv6)
|
|
Printing protocols
|
LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP, FPT for downloading print files, IPP, SMB, WSD
|
|
Available Fonts
|
80 PCL, 139 PostScript 3
|
|
Copy
|
|
Original paper size: Max.
|
A3
|
|
First copy out time: Colour (sec.)
|
7.6
|
|
First copy out time: B/W (sec.)
|
5.6
|
|
E-sort
|
Option
|
|
Continuous copy (Max. copies)
|
9999
|
|
Scan resolution: B/W (dpi)
|
600 x 600, 600 x 400
|
|
Scan resolution: Colour (dpi)
|
600 x 600
|
|
Print resolution (dpi)
|
1200 x 1200, 600 x 600, 9600 x 600
|
|
Gradation: Colour (equivalent levels)
|
256
|
|
Zoom range: Min. (%)
|
25
|
|
Zoom range: Max. (%)
|
400
|
|
Preset copy ratios
|
10
|
|
Scan method
|
Push scan, Pull scan
|
|
Scan
|
|
Network scanner
|
Standard
|
|
Push scan resolution (dpi)
|
100, 150, 200, 300, 400, 600
|
|
Pull scan resolution (dpi)
|
75, 100, 150, 200, 300, 400, 600, 50-9600
|
|
File formats: Std.
|
TIFF, PDF, PDF/A-1a, PDF/A-1b, Encrypted PDF, Compact PDF, JPEG, XPS, Searchable PDF, Microsoft Office (pptx, xlsx, docx), Text (TXT), Rich Text (RFT)
|
|
Scan destinations
|
Desktop, FTP, Email, Network folder, USB
|
|
Fax
|
|
Fax
|
Option
|
|
Compression method
|
MH, MR, MMR, JBIG
|
|
Communication protocol
|
Super G3, G3
|
|
Transmission time (sec.)
|
2
|
|
Modem speed: Min. (bps)
|
2400
|
|
Modem speed: Max. (bps)
|
33600
|
|
Transmission resolution: Std (dpi)
|
203.2 x 97.8 dpi
|
|
Transmission resolution: Ultra Fine (dpi)
|
406.4 x 391 dpi
|
|
Document size: Min.
|
A5
|
|
Document size: Max.
|
A3
|
|
Memory: Max. (GB)
|
4
|
|
Grey scale (levels)
|
256
|
|
Dial registration: rapid/speed dial
|
2000
|
|
Broadcast transmission (Max. destinations)
|
500
|
|
File
|
|
Document filing
|
Standard
|
|
Stored jobs
|
Copy, Print, Scan, Fax transmission
|
|
Storage folders
|
Quick file, Main, Custom
|
|
Confidential storage
|
No
|
|
Finish
|
|
Finishing
|
Available
|
|
Output capacity: Min. (sheets)
|
500
|
|
Output capacity: Max. (sheets)
|
3250
|
|
Staple capacity: Max. (sheets)
|
65
|
|
Saddle stitch
|
Option
|
|
Off-set shifting
|
Standard
|
|
Hole punch
|
Option
|
|
Wireless Lan
|
|
Wireless LAN
|
Standard
|
|
Compliant regulation
|
IEEE802.11a/ac/b/g/n
|
|
Access mode
|
Infrastructure mode, Software AP mode
|
|
Security
|
WEP, WPA/WPA2-mixed PSK, WPA/WPA2-mixed EAP, WPA2 PSK, WPA2 EAP, WPA2 EAP/WPA3-mixed, PSK/SAE, WPA3 SAE, WPA2/WPA3-mixed, EAP, WPA3 EAP
|
|
Toner Yield
|
|
Black (pages at 5% coverage)
|
40000
|
|
Cyan (pages at 5% coverage)
|
24000
|
|
Magenta (pages at 5% coverage)
|
24000
|
|
Yellow (pages at 5% coverage)
|
24000
|
|
Others
|
|
Power Requirements: voltage Min. (V)
|
200
|
|
Power Requirements: voltage Max. (V)
|
240
|
