| Camera |
| Image Sensor | Overview channel: 1/2.8" CMOS; Detail channel: 1/2.8" CMOS |
| Pixel | Overview channel: 8 MP; Detail channel: 4 MP |
| Max. Resolution | Overview channel: 5376 (H) x 1520 (V); Detail channel: 2560 (H) x 1440 (V) |
| ROM | Overview channel: 4 GB; Detail channel: 4 GB |
| RAM | Overview channel: 2 GB; Detail channel: 1GB |
| Electronic Shutter Speed | Overview channel: 1 s–1/100,000 s; Detail channel: 1 s–1/30,000 s |
| Scanning System | Progressive |
| Min. Illumination | Overview channel:
0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE);
0 lux (illuminator on)
Detail channel:
1 s–1/30,000 s
0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE);
0 lux (illuminator on) |
| Illumination Distance | Overview channel:
30 m (98.43 ft) (IR);
30 m (98.43 ft) (white light)
Detail channel:
70 m (229.66 ft);
30 m (98.43 ft) (white light) |
| Illuminator On/Off Control | Overview channel: Manual; Auto; Off
Detail channel: Zoom Prio; Manual; Auto; Off |
| Illuminator Number | Overview channel: 2 (IR light); 2 (white light); Detail channel: 2 (Dual light fusion); 2 (IR light) |
| Lens |
| Focal Length | Overview channel: 2.8 mm; Detail channel: 4 mm–40 mm |
| Max. Aperture | Overview channel: F1.6; Detail channel: F1.6-F3.6 |
| Field of View | Overview channel: H: 180°; V: 47°;
Detail channel: H: 58°–11.3°; V: 33.1°–6.4°; D: 66.4°–12.8° |
| Optical Zoom | Overview channel: NA; Detail channel: 10x |
| Focus Control | Auto; manual; semi-auto |
| Close Focus Distance | Overview channel: 0.6 m (1.97 ft); Detail channel: 0.1 m–0.5 m (0.33 ft–1.64 ft) |
| Iris Control | Overview channel: NA; Detail channel: NA |
| DORI Distance | Detect | Observe | Recognize | Identify |
| 500 m (1640.42 ft) | 197.5 m (647.97 ft) | 100 m (328.08 ft) | 50 m (164.04 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
| PTZ |
| Pan/Tilt Range | Pan: 0° to 345°;
Tilt: -10° to +90° |
| Manual Control Speed | Overview channel: NA; Detail channel: H: 0.1°–80°/s; V: 0.1°–50°/s |
| Preset Speed | H: 80°/s; V: 50°/s |
| Preset | 300 |
| Power-off Memory | Yes |
| Idle Motion | Preset |
| Intelligence |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human/vehicle alarm classification; linkage tracking (only for people) |
| Face Detection | Detail channel: Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. |
| SMD | SMD 4.0 |
| SMD | Yes |
| Active Deterrence |
| Light Warning | Red and blue light warning;
Flash duration: 5 s–30 s;
Flash frequency: high, medium, low |
| Sound Warning | Offers 11 sound alarm and 10 custom sound alarms can be imported.
Sound can be set from 0%–100%.
Play times can be set from 1-10. |
| Video |
| Video Compression | H.264H; H.264B; Smart H.265+; H.265; Smart H.264+; H.264M; MJPEG (Sub Stream 1) |
| Streaming Capability | 3 streams |
| Resolution | Overview channel: 5376 x 1520; 26886 x 752; 1080p (1920 x 1080); 720p (1280 x 720); 1344 x 368; D1 (704 x 576/704 x 480); CIF (352 x 288/352 x 240);
Detail channel: 2560 x 1440; 3M (2304 x 1296); 1080p (1920 x 1080); 1280 x 960 (1.3M); 720p (1280 x 720); D1 (704 x 576/704 x 480); CIF (352 x 288/352 x 240) |
| Video Frame Rate | Overview channel: Main stream: 5376 x 1520 @(1–25/30 fps)
Sub stream 1: 1344 x 368/D1/VGA/CIF@ (1–25/30 fps)
Sub stream 2: 2688 x 752/1080p/1.3M/720p @(1–25/30 fps);
Detail channel: Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@ (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/ @(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | Overview channel: H264: 128 kbps–16,384 kbps
H265: 51 kbps–13,312 kbps;
Detail channel: H264: 96 kbps–16,384 kbps
H265: 38 kbps–10,240 kbps |
| Day/Night | Overview channel: Auto; Color; B/W;
Detail channel: Auto; Color; B/W; Electronic |
| BLC | Yes |
| WDR | Overview channel: DWDR
Detail channel: 120 dB |
| HLC | Yes |
| White Balance | Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Overview channel: Auto; manual; gain prio
Detail channel: Auto; manual; gain prio |
| Noise Reduction | Overview channel: 2D NR; 3D NR
Detail channel: 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Overview channel: NA
Detail channel: Electronic Image Stabilization (EIS) |
| Defog | Overview channel: Electronic
Detail channel: Electronic |
| Digital Zoom | Overview channel: NA
Detail channel: 16x |
| Image Rotation | Overview channel: NA
Detail channel: 180° |
| S/N Ratio | Overview channel: ?55dB
Detail channel: ?55dB |
| Audio |
| Audio Compression | Overview channel: PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729;
Detail channel: NA |
| Network |
| Network Port | RJ-45 (100 Base-T) |
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; QoS; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; RTSP; ARP |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser | web5.0:
IE 9 and later versions;
Chrome 41 and later versions;
Firefox 50 and later versions;
Safari 10 and later versions |
| Management Software | DMSS; DSS Pro |
| Mobile Client | iOS; Android |
| Certification |
| Certifications | CE: EN55032/EN55035/IEC61000-3-2/IEC61000-3-3/EN62368-1/IEC62471 |
| Port |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)) |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input | 1 (on-off value input: 0–5 VDC) |
| Alarm Output | 1 channel |
| Alarm Linkage | Capture; recording; send email; preset; alarm digital output; audio; warning light |
| Alarm Event | Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 12 VDC, 3 A ± 10%
PoE+(802.3at) |
| Power Consumption | Basic: 12 W;
Max: 25 W (illuminator + heating glass + siren and light active deterrence + PTZ) |
| Environment |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | ?95% |
| Protection | TVS 6000 V lightning proof; IP66; surge protection; voltage transient protection |
| Structure |
| Product Dimensions | 140.3 mm x 181.7 mm x 238.8 mm (5.52" x 7.15" x 9.40") (L x W x H) |
| Net Weight | 2.17 kg (4.78 lb) |
| Gross Weight | 3.1 kg (6.83 lb) |
| The precision of the presets for PTZ cameras might vary depending on different series. For scenes with high requirements on the precision, contact your local sales representative for assistance with selecting the model. |
