| Camera |
| Image Sensor | 1/2.8”8Megapixel progressive CMOS |
| Max. Resolution | 3840 (H) Ч 2160 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.007 Lux@F1.5 (Color, 30IRE) 0.0007 Lux@F1.5 (B/W, 30IRE) 0 Lux (Illuminator on) |
| S/N Ratio | > 56 dB |
| Illumination Distance | 40 m (131.2 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 2 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355° |
| Lens |
| Lens Type | Motorized vari-focal |
| Mount Type | ?14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max. Aperture | F1.5 |
| Field of View | Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal: 138°–36° |
| Iris Type | Fixed |
| Close Focus Distance | 0.8 m (2.6 ft) |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| W | 85.3 m (279.9 ft) | 34.1 m (111.9 ft) | 17.0 m (55.8 ft) | 8.5 m (27.9 ft) |
| T | 280.0 m (918.6 ft) | 112.0 m (367.5 ft) | 56.0 m (183.7 ft) | 28.0 m (91.9 ft) |
| Professional, intelligent |
| Perimeter Protection | Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+/ Smart H.264+ |
| Video Frame Rate | Main stream: 3840 Ч 2160 @(1–20 fps by default) 3840 Ч 2160 @(1–25/30 fps when AI function disabled) sub stream: 704 Ч 576 @(1–25 fps)/704 Ч 480 @ (1–30 fps) third stream: 1920 Ч 1080 @(1–25/30 fps) |
| Stream Capability | 3 streams |
| Resolution | 8M (3840 Ч 2160); 6M (3072 Ч 2048); 5M (3072 Ч 1728/2592 Ч 1944); 4M (2688 Ч 1520); 3M (2048 Ч 1536/2304 Ч 1296); 1080p (1920 Ч 1080); 1.3M (1280 Ч 960); 720p (1280 Ч 720); D1(704 Ч 576/704 Ч 480); VGA (640 Ч 480); CIF (352 Ч 288/352 Ч 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
| Audio Compression | G.711a; G.711Mu; G726 |
| Alarm |
| Alarm Event | - ZAS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
-ZS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; defocus detection; SMD; safety exception |
| Network |
| Network | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
| User/Host | 20 (Total bandwidth: 72 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser | IE: IE8; IE9; IE11
Chrome
Firefox |
| Management Software | Smart PSS; DSS; DMSS |
| Mobile Phone | IOS; Android |
| Certification |
| Certifications | CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Port |
| Audio Input | 1 channel (RCA port) (Only - ZAS supports) |
| Audio Output | 1 channel (RCA port) (Only - ZAS supports) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC (Only - ZAS supports) |
| Alarm Output | 1 channel out: 300mA 12V DC (Only - ZAS supports) |
| Power |
| Power Supply | 12V DC/PoE (802.3af) |
| Power Consumption | Basic power consumption: 2.7W (12V DC); 3.3W (PoE) Max. power consumption (WDR + H.265 + IR LED intensity): 6.8W (12V DC); 8.2W (PoE) |
| Environment |
| Operating Conditions | –30°C to +60°C (–22°F to +140°F)/Less than 95% RH |
| Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
| Protection Grade | IP67; IK10 |
| Structure |
| Casing | Metal |
| Dimensions | 88.9 mm Ч ?122 mm (3.5" Ч ?4.8") |
| Net Weight | 492 g (1.1 lb) |
| Gross Weight | 663 g (1.5 lb) |
